Module FIDs and Supported Hardware

The module is categorized by specific Flash Identification (FID) protocols based on the MCU type and connection method:

• FID 149 (OBD): Supports Renesas R7F701202/R7F701216 MCUs with 4MB flash memory. It allows for software identification, reading, and writing with checksum correction via the OBD port.

• FID 235/236 (BENCH-CAN): Designed for Type 2 systems, allowing software identification, virtual reading, and writing on the bench.

• FID 345 (BENCH-CAN): Designed for Type 3 systems, allowing software identification, real reading on the bench, and writing on the bench. This FID can be used for real reading of the 3.3TD F33AFTV engine.

Supported Vehicles and Engines

This module covers a wide array of modern Toyota and Lexus applications:

Critical Technical Notes

• Safety Warning: Writing a modified (MOD) file with incorrect DTC (Diagnostic Trouble Code) disabling can result in a permanent ECU failure with no possibility of recovery.

• Full Integration: This module is included in the BitBox Toyota Full package, which also covers generations 1, 2, and 4, as well as Delphi Gen1 systems.

• Editing Capability: Files read with this module can be edited using the Toyota Denso Diesel 7 BitEdit module for diesel 1GDFTV and F33AFTV engines.
